ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-140
© 2000, ADC Telecommunications, Inc.
DLP-541
Page 11 of 16
Low Speed Loopback Status/Commands
Group: 1 DS1#: 4
Location - LOCAL REPEATER1 REPEATER2 REMOTE
========== ========== ========== ==========
COMMANDS:
Loopback:
STATUS:
Unit Type: HLXC HRX1 HRX2 HLXR
+--------+ +--------+ +--------+ +--------+
| | | | | | | |
-------->|------->|------>|--+ +->|------>|--------|------>|------->|----->
NETWORK | | | | | | | | | | CUST
DS1 | | HDSL | | | | HDSL | | HDSL | | DS1
| | | | | | | | | |
<--------|<-------|<------|<-+ +--|<------|<-------|<------|<-------|<-----
|net cust| |net cust| |net cust| |net cust|
+--------+ +--------+ +--------+ +--------+
Programmable Loopback Armed State: ARMING DISABLED
Press CONTROL-A For Assistance
11384-A
Figure 541-9a. HRX1
Customer Loopback Screen (Two HRXs)
Low Speed Loopback Status/Commands
Group: 1 DS1#: 4
Location - LOCAL REPEATER1 REPEATER2 REMOTE
========== ========== ========== ==========
COMMANDS:
Loopback:
STATUS:
Unit Type: HLXC HRX1 HRX2 HLXR
+--------+ +--------+ +--------+ +--------+
| | | AIS| | | | |
-------->|------->|------>|--+ +->|------>|--------|------>|------->|----->
NETWORK | | | | | | | | | CUST
DS1 | | HDSL | | | HDSL | | HDSL | | DS1
| | | | | | | | |
<--------|<-------|<------|<-+ +--|<------|<-------|<------|<-------|<-----
|net cust| |net cust| |net cust| |net cust|
+--------+ +--------+ +--------+ +--------+
Programmable Loopback Armed State: ARMING DISABLED
Press CONTROL-A For Assistance
11380-A
Figure 541-9b. HRX1
Network Loopback Screen (Two HRXs)
