e-STUDIO281c/351c/451c SPECIFICATIONS/ACCESSORIES/OPTIONS/SUPPLIES June 2005 © TOSHIBA TEC
1 - 6
yEliminated portion.................... Leading edges: 3.0±2.0 mm, Side/trailing edges: 2.0±2.0 mm (black
copy)
Leading edges: 5.0±2.0 mm, Side/trailing edges: 2.0±2.0 mm (color
copy)
Leading / trailing edges: 5.0±2.0 mm, Side edges: 5.0±2.0 mm (black /
color print)
yPaper feeding.......................... Standard drawers:
2 drawers (stack height 60.5 mm, equivalent to 550 sheets; 64 to 80 g/
m
2
(17 to 22 lb. Bond))
PFP:
Option (One drawer or two: stack height 60.5 mm, equivalent to 550
sheets; 64 to 80 g/m
2
(17 to 22 lb. Bond))
LCF:
Option (Stack height 137.5 mm x 2: equivalent to 2500 sheets; 64 to 80
g/m
2
(17 to 22 lb. Bond))
Bypass feeding:
Stack height 11 mm: equivalent to 100 sheets; 64 to 80 g/m
2
(17 to 22
lb. Bond)
yCapacity of originals in the reversing automatic document feeder (Option)
.................................................. A3 to A5-R, LD to ST-R:
100 sheets / 80 g/m
2
(Stack height 16 mm or less)
yAutomatic duplexing unit ......... Stackless, Switchback type
yToner supply............................ Automatic toner density detection/supply
Toner cartridge replacing method
yDensity control......................... Automatic density mode and manual density mode selectable in 11
steps
yWeight ..................................... Approximately 113 kg (249 lb.)
yPower requirements ................ AC 110 V / 13.2 A, 115 V or 127 V / 12 A
220-240 V or 240 V / 8 A (50/60 Hz)
* The acceptable value of each voltage is ±10%.
yPower consumption................. 1.5 kW or less (100 V series), 17 kW or less (200 V series)
* The electric power is supplied to the RADF, Finisher, PFP and LCF through the equipment.
yTotal counter............................ Electronical counter
yDimensions of the equipment...................... See the figure below (W 660 x D 758 x H 739 (mm))
* When the tilt angle of the control panel is 45 degrees.
Fig.1-1
660
758
45°
739
