e-STUDIO281c/351c/451c ADJUSTMENT June 2005 © TOSHIBA TEC
3 - 40
3.6.6 Upper limit value at Toner Saving Mode
The upper limit value is adjusted at the Toner Saving Mode.
<Adjustment Mode (05)>
<Procedure>
Procedure is same as that of “3.6.5 Adjustment of smudged/faint text”.
3.6.7 Dot size adjustment in black printing
The dot size is adjusted in primary scanning direction in black printing.
<Adjustment Mode (05)>
<Procedure>
Procedure is same as that of “3.6.5 Adjustment of smudged/faint text”.
3.6.8 Maximum toner density adjustment to paper type
The maximum toner amount adhering to the paper can be controlled.
<Adjustment Mode (05)>
<Procedure>
Procedure is same as that of “3.6.3 Gamma balance adjustment”.
Note: Note:
The larger the value is, the more frequently fusing offsetting occurs.
3.6.9 Image processing: Gamma correction table all clearing
The state of calibration in color printing mode is initialized at the Setting Mode (08-597). This setting is
to be performed when a defect occurs in “Automatic gamma adjustment (05-1000 to 1003)”. The cause
of defect is presumed as an image failure (jittering or uneven image density) at the patch chart for
gamma adjustment.
Black mode Language
Remarks
PS PCL
PS PS PCL PCL
600x600dpi 1200x600dpi 600x600dpi 1200x600dpi
664 665 1055 1056 1057 1058 The smaller the value is, the lighter
the density of image becomes.
Acceptable values: 0 to 255.
(Default: 176)
Code Remarks
663 The smaller the value is, the dot size becomes smaller.
Acceptable values: 0 to 255. (Default: 255)
Code
Paper type Remarks
PS PCL
1046-0 1046-1 Plain paper The smaller the value is, the toner amount adhered
decreases of the high density area (ex. prevention of fusing
offsetting, etc).
Acceptable values: 0 to 255. (Default: Plain paper: 255, Thick
paper 1:
255, Thick paper 2: 255, Thick paper 3: 255, OHP film: 200)
1047-0 1047-1 Thick paper 1
1048-0 1048-1 Thick paper 2
1049-0 1049-1 Thick paper 3
1050-0 1050-1 OHP film
