e-STUDIO281c/351c/451c ERROR CODE AND SELF-DIAGNOSTIC MODE June 2005 © TOSHIBA TEC
2 - 26
[FAX] button: OFF/[COPY] button: OFF ([FAX] LED: OFF/[COPY] LED: OFF)
Digital
key
Button Items to check
Contents
Highlighted display
e.g.
Normal display
e.g.
[1]
A Bypass unit connection Not connected Connected
B ADU connection Not connected
Connected
C-
--
D LCF connection Not connected
Connected
E-
--
F-
--
G-
--
H LCF drawer detection switch Drawer not installed Drawer present
[2]
A PFP upper drawer detection switch Drawer not installed
Drawer present
B-
--
C PFP upper drawer paper stock sensor Paper almost empty Paper present
D PFP upper drawer feed sensor Paper present No paper
E PFP connection Not connected Connected
F PFP side cover open/close switch Cover opened Cover closed
G PFP upper drawer empty sensor No paper Paper present
H PFP upper drawer tray-up sensor Tray at upper limit
position
Other than upper
limit position
[3]
A LCF tray bottom sensor Tray at bottom posi-
tion
Other than upper
limit position
B LCF standby side paper misload detection sen-
sor
Properly loaded Paper misload
C-
--
D-
--
E-
--
F-
--
G-
--
H Paper stock sensor at LCF feed side Paper present No paper
[4]
A PFP lower drawer detection switch Drawer not installed Drawer present
B-
--
C PFP lower drawer paper stock sensor Paper almost empty Paper present
D PFP lower drawer feed sensor Paper present
No paper
E PFP motor rotation status (Motor is rotating at
output mode (03))
Abnormal rotation Normal rotation
F-
--
G PFP lower drawer empty sensor No paper Paper present
H PFP lower drawer tray-up sensor Tray at upper limit
position
Other than upper
limit position
