June 2005 © TOSHIBA TEC e-STUDIO281c/351c/451c PREVENTIVE MAINTENANCE (PM)
4 - 9
4
4.2 General Descriptions for PM Procedure
(1) Preparation
• Ask the user about the current conditions of the equipment and note them down.
• Before starting maintenance, make some sample copies and store them.
• See the replacement record and check the parts to be replaced in the PM support mode (6S-
2) or list printing mode (9S-103).
6S-2 : [6] + [START] + [POWER] ON Æ [2] Æ [START]
9S-103 : [9] + [START] + [POWER] ON Æ [103] Æ [START]
Fig.4-7
• Turn OFF the power and make sure to unplug the equipment.
(2) Perform a preventive maintenance using the following checklist and illustrations. Refer to the
Service Manual if necessary.
(3) Plug in the equipment after the maintenance has been finished. Then turn ON the power and
make some copies to confirm that the equipment is working properly.
PM SUPPORT CODE LIST
XX-XX-'XX 11:28
UNIT OUTPUT PAGES/ PM OUTPUT PAGE/ DRIVE COUNTS PM DRIVE COUNTS
DEVELOP COUNTS DEVELOP COUNTS
DRUM 22220 200000 30948 320000
DRUM BLADE 22220 200000 30948 320000
DRUM BRUSH 22220 200000 30948 320000
GRID 22220 200000 30948 320000
MAIN CHARGER WIRE 22220 200000 30948 320000
WIRE CLEANING PAD 22220 200000 30948 320000
