June 2005 © TOSHIBA TEC e-STUDIO281c/351c/451c ERROR CODE AND SELF-DIAGNOSTIC MODE
2 - 3
2
E210 Paper transport jam Lower drawer transport jam (Paper not reaching the
registration sensor): The paper does not reach the
registration sensor after it has passed the upper
drawer feed sensor.
Ch.5.1.3
E220 Lower drawer transport jam (Paper not reaching the
upper drawer feed sensor): The paper does not
reach the upper drawer feed sensor after it has
passed the lower drawer feed sensor.
Ch.5.1.3
E300 PFP upper drawer transport jam (Paper not reach-
ing the registration sensor): The paper does not
reach the registration sensor after it has passed the
upper drawer feed sensor.
Ch.5.1.3
E310 PFP upper drawer transport jam (Paper not reach-
ing the upper drawer feed sensor): The paper does
not reach the upper drawer feed sensor after it has
passed the lower drawer feed sensor.
Ch.5.1.3
E320 PFP upper drawer transport jam (Paper not reach-
ing the lower drawer feed sensor): The paper does
not reach the lower drawer feed sensor after it has
passed the PFP upper drawer feed sensor.
Ch.5.1.3
E330 PFP lower drawer transport jam (Paper not reach-
ing the registration sensor): The paper does not
reach the registration sensor after it has passed the
upper drawer feed sensor.
Ch.5.1.3
E340 PFP lower drawer transport jam (Paper not reach-
ing the upper drawer feed sensor): The paper does
not reach the upper drawer feed sensor after it has
passed the lower drawer feed sensor.
Ch.5.1.3
E350 PFP lower drawer transport jam (Paper not reach-
ing the lower drawer feed sensor): The paper does
not reach the lower drawer feed sensor after it has
passed the PFP upper drawer feed sensor.
Ch.5.1.3
E360 PFP lower drawer transport jam (Paper not reach-
ing the PFP upper drawer feed sensor): The paper
does not reach the PFP upper drawer feed sensor
after it has passed the PFP lower drawer feed sen-
sor.
Ch.5.1.3
E400 Cover open jam Jam access cover open jam: The jam access cover
has opened during printing.
Ch.5.1.3
E410 Front cover open jam: The front cover has opened
during printing.
Ch.5.1.5
E420 Cover open jam PFP side cover open jam: The PFP side cover has
opened during printing.
Ch.5.1.5
E430 ADU open jam: The ADU has opened during print-
ing.
Ch.5.1.5
E440 Side cover open jam: The side cover has opened
during printing.
Ch.5.1.5
E450 LCF side cover open jam: The LCF side cover has
opened during printing.
Ch.5.1.5
E480 Bridge unit open jam: The bridge unit has opened
during printing.
Ch.5.1.5
E510 Paper transport jam
(ADU section)
Jam not reaching the ADU entrance sensor: The
paper does not reach the ADU entrance sensor
after it is switchbacked in the exit section.
Ch.5.1.3
E520 Stop jam in the ADU: The paper does not reach the
ADU exit sensor after it has passed the ADU
entrance sensor.
Ch.5.1.3
Error code Classification Contents Troubleshooting
