On Screen Display 381
Configure Menu Overview
Destination IP
The IP address of an output packet’s destination.
Destination Mask
The netmask of the subnet to which an output packet is going.
Protocol
Choices are “All,” “Numeric,” “TCP,” “UDP,” “ICMP.”
Protocol Number
Appears only if “Numeric” is selected from the “Protocol”
menu.
Source Port
Appears only if “TCP” or “UDP are selected from the
“Protocol” menu. The source port number.
Destination Port
Appears only if “TCP” or “UDP are selected from the
“Protocol” menu. The destination port number.
Table 7-9: IP Filtering Configuration Screens [OSD] (Continued)
Screen Description
