4. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO18-33027
4. INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT
4- 1
4. INSTALLATION PROCEDURE FOR OPTIONAL
EQUIPMENT
WARNING!
1. Follow all manual instructions. Failure to do so could create safety hazards such as fire or
electrocution.
• Manual instructions must be followed when installing option kits or adding cables to avoid system
failures and to insure proper performance and operation.
2. Make sure to unplug the power cord before installing the optional equipment.
3. Be careful not to pinch your fingers or hands with the covers.
4. The print head and stepping motor becomes very hot immediately after printing. Do not touch the print
head, stepping motor and around it right after printing, or you may get burned.
5. When opening the top cover, it must be fully opened. Failure to do this may cause the top cover to
close under its own weight, resulting in an injury.
CAUTION!
When replacing parts or performing maintenance on the printer, be careful not to damage the print head
with a hard object like a watch or a ring.
Since the print head element can be easily damaged by shock, please treat it carefully by not hitting a hard
object against it.
The following optional kits are provided for this printer.
● B-EX204-QM-R: Disc cutter ● B-EX904-PK-QM-R: Narrow width platen kit
● B-EX204-R-QM-R: Rotary cutter ● B-EX700-WLAN-QM-R: Wireless LAN I/F card
● B-EX904-H-QM-R: Peel off module ● B-EX700-RTC-QM-R: RTC/USB host I/F card
● B-EX904-R-QM-R: Ribbon Saving Module ● B-EX700-IO-QM-R: Expansion I/O card
● B-EX700-CEN-QM-R: Parallel I/F card ● B-EX700-RS-QM-R: Serial I/F card
● B-EX700-RFID-H1-QM-R: HF RFID module mount kit
● B-EX700-RFID-U2-EU-R: UHF RFID kit for EU
● B-EX700-RFID-U2-US-R: UHF RFID kit for US
● B-EX700-RFID-U2-CN-R: UHF RFID kit for CN
In this section, installation procedures for these optional equipments are described.
Care must be taken not to allow the
metal or glass part of a watch to touch
the print head edge.
Care must be taken not to allow a
metal object like a ring to touch the
print head edge.
