18-22
Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
OL-16506-17
Chapter 18 LSM-MLDP-based MVPN Support
Router#show platform software mpls rp active replicate
Replicate-oce-list: 0x400000d2 (1 OCEs)
OM: 0x42269b64
Replicate-oce-list: 0x400000d3 (1 OCEs)
OM: 0x43ba2aec
Replicate-oce-list: 0x400000d4 (0 OCEs)
OM: 0x422659bc
Replicate-oce-list: 0x400000d5 (0 OCEs)
OM: 0x422658ac
• To display the Replicate OCE with the specified index value on FMAN RP, use show platform
software mpls rp act-status replicate index index-value command.
Note You should run "show platform software mpls rp active replicate" first to see the all the replicated
OCE on the FMAN RP.
Router#show platform software mpls fp active replicate
Replicate-oce-list: 0x84 (1 OCEs)
AOM obj: 478, HW list: 0x11b19610 (created)
Router#show platform software mpls rp active replicate index 0x84 Replicate-oce-list
entries
OCE Type Misc Info
------------------------------------------------------------------------------------
0xa3 OBJ_LABEL aom id: 494, HW info: 0x11b19e40
(created)
• To display all the replicated OCE on the FMAN FP, use show platform software mpls fp act-status
replicate command.
Router#show platform software mpls fp active replicate
Replicate-oce-list: 0x400000d2 (1 OCEs)
AOM obj: 352887, HW list: 0x11a65628 (created)
Replicate-oce-list: 0x400000d3 (1 OCEs)
AOM obj: 352889, HW list: 0x10d4a518 (created)
Replicate-oce-list: 0x400000d4 (0 OCEs)
AOM obj: 352891, HW list: 0x139e3d90 (created)
Replicate-oce-list: 0x400000d5 (0 OCEs)
AOM obj: 352894, HW list: 0x139e7cb8 (created)
• To display the complete OCE chain used for forwarding traffic to a particular IPv4 multicast address,
use show platform hardware qfp active feature multicast v4mcast ip-address-mgroup
ip-address-source vrf vrf-id extension command.
Router#show platform hardware qfp active feature multicast v4mcast 239.1.1.1/32 vrf 2
extension
Root: 0x1187fc58
Flags: 0x000002
First leaf: 0x11887fa8
Number of nodes: 1
Number of leaves: 3
RPF i/f: 0x01fff7
Punt limit counter: 200
NS DCS Punt limit: 0x000001
RPF Fast Convergence Flags: 00000000
Secondary RPF interface: 00000000
