7-44 Parts and DiagramsHP DesignJet CP Series Printers
Refill Interconnect PCA and Cutter Assembly
Reference
HP Part Number
Quantity Description
on
Drawing
DesignJet
2X00CP
DesignJet
3X00CP
1 0515-1743 0515-1743 2 Screw (T-20)
2 C4704-60009 C4704-60009 1 Refill Interconnect PCA
3 0515-2200 0515-2200 2 Screw (T-10)
4 C4704-60040 C4723-60040 1 Bail Motor
5 C4704-60019 C4723-60244 1 Cutter Assembly (See
Note below)
6 C3195-40076 C3195-40076 1 Cutter Bushing
Note: Part Number C4704-60019 is Applicable to HP DesignJets 2X00CP
with Serial Number Format ESAXXXXXX and ESBXXXXXX.
Note: Part Number C4723-60244 is Applicable to HP DesignJets 3X00CP
and to HP DesignJets 2X00CP with Serial Number Format ESCXXXXXX.
