6
Configuring an F_Port Extension over an Ethernet WAN
6-3
Configuring a 2x2 Ethernet Wide Area Network
You will need the following addresses:
• UltraNet Edge 3000 Ethernet Maintenance Interface IP host
address
• Default Gateway IP host address for the UltraNet Edge 3000
Ethernet Maintenance Interface
• UltraNet Edge 3000 Ethernet WAN Interface IP host address(es)
• Router IP host address (default gateway for the WAN data path)
attached to the UltraNet Edge 3000 Ethernet WAN Interface
When an UltraNet Edge 3000 is configured for F_port, the internal
Fibre Channel switch (FCSW) application is used instead of an
external Fibre Channel switch.
NOTE: For more detail on valid configuration options, see the “Valid
Hardware Interface Configurations” section in Chapter 2.
Starting UltraNet
ConfigManager
This section explains how to start the UltraNet ConfigManager
software and provides information about the UltraNet ConfigManager
Online Tutorial.
You will have the option to use the Online Tutorial when you first
open the UltraNet ConfigManager software. You can use either the
Online Tutorial or this chapter of the UltraNet Edge Storage Router 3000
Series User Guide to create a sample network of a 2x2 F_port Gigabit
Ethernet WAN.
Start the UltraNet ConfigManager application from either the icon
on your desktop or the Start menu.
