McDATA UltraNet Edge 3000 User Guide
Configuring Tape Device Extension
• Default Gateway IP host address for the UltraNet Edge 3000
Ethernet Maintenance Interface
• UltraNet Edge 3000 Ethernet WAN Interface IP host address(es)
• Router IP host address (default gateway for the WAN data path)
attached to the UltraNet Edge 3000 Ethernet WAN Interface
Starting UltraNet
ConfigManager
This section explains how to start the UltraNet ConfigManager
software and provides information about the UltraNet ConfigManager
Online Tutorial.
The UltraNet ConfigManager (UCM) application is used to configure
the UltraNet Edge 3000. You will have the option to use the Online
Tutorial when you first open the UCM software. You can use either
the UCM Online Tutorial or this chapter of the UltraNet Edge Storage
Router - 3000 Series User Guide to create a sample network of a 1x1
10/100 Ethernet WAN for FC/SCSI Tape Pipelining. If you prefer to
follow an example of a 2x2 configuration, refer to the UltraNet
ConfigManager Online Help.
The UltraNet ConfigManager application can be opened from either
the icon on your desktop or the Start/Programs menu.
Figure 9-4 UltraNet ConfigManager Main Window
Tree
View
Area
Network
Map
Area
