McDATA UltraNet Edge 3000 User Guide
Front and Rear View of UltraNet Edge 3000 Chassis
NOTE: If the motherboard, compression card, or flash disk are deemed
defective, the whole chassis will need to be replaced.
Front and Rear View of UltraNet Edge 3000 Chassis
Figure 0-1 Field Replaceable Units (FRUs)
Replacing the UltraNet Edge 3000 Chassis
For replacement purposes, when the UltraNet Edge 3000 “chassis” is
referred to, it assumes that the following components are included as
part of the chassis replacement unit:
• Power Supplies
•Fan Assembly
• Motherboard
Fan Assembly (4)
Sb116
Front View
Back View
Redundant Power Supply
Power Supply
10/100 Ethernet or
Gigabit Ethernet Interfaces
OC-3 ATM/POS
Fibre Channel Interfaces
(1 Gigabit or 2 Gigabit)
I/O 4
I/O 2
I/O 1
I/O 3
