McDATA UltraNet Edge 3000 User Guide
Typical Configuration of the UltraNet Edge 3000
ATM WAN
Configurations
1x1 and 2x2 configurations are standard ATM WAN configurations
for the UltraNet Edge 3000. The UltraNet Edge 3000 can also be
configured in a 1x2, 2x1 and 3x1 configurations, but they are not
supported as standard implementations.
The 1x1 configuration consists of:
• One Fibre Channel interface extended over one OC-3 ATM WAN
• aces extended over one OC-3 ATM WAN
The 2x2 configuration consists of:
• Two Fibre Channel interfaces extended over two OC-3 ATM
WANs
FC/SCSI Tape
Pipelining
The UltraNet Edge 3000 can be configured for FC/SCSI taep
pipelining over in a 1x1, or 2x2 Ethernet or ATM WAN
configurations.
The 1x1 configuration consists of:
• One Fibre Channel Device Extension interface extended over one
10/100 Ethernet, Gigabit Ethernet, or OC-3 ATM WAN
The 2x2 configuration consists of:
• Two Fibre Channel Device Extension interfaces extended over
two 10/100 Ethernet, Gigabit Ethernet, or OC-3 ATM WANs
