B
B-54
McDATA® Sphereon 3032 and 3232 Installation and Service Manual
Event Code Tables
Distribution: Switch EFC Server Host
Nonvolatile
System
Event Log
System
Error
Indicator
Event Log E-Mail Call-Home Sense Info Link Incident
✔✔
Event Code: 508
Message: Fibre Channel port anomaly detected
Severity: Informational
Explanation: Indicates that the control processor has detected a deviation in the normal operating mode or operating status of
the indicated port.
Action: No action required. There will be an additional event generated (506) if the diagnostic failure incident results in a
port failure.
Event Data: Byte 0 = Port number (00-8F)
Byte 1 = Anomaly reason code (See following chart)
Bytes 4-7 = Elapsed millisecond tick count
Bytes 8-9 = High availability error callout #1 (Internally defined)
Bytes 10-11 = High availability error callout #2 (Internally defined)
Byte 12 = Detecting port
Byte 13 = Connected port
Byte 14 = Participating SBAR
Bytes 16-17 = High Availability error callout #3 (Internally defined)
Bytes 18-19 = High Availability error callout #4 (Internally defined)
Distribution: Switch EFC Server Host
Nonvolatile
System
Event Log
System
Error
Indicator
Event Log E-Mail Call-Home Sense Info Link Incident
✔✔
Event #508 Anomaly Reason Codes
Reason Code Description Additional Data
0x00 Utility bus error to SBAR HA Error Callouts (Words 2 & 4)
0x01 Utility bus error to Port Module HA Error Callouts (Words 2 & 4)
