Introduction
2
VG-Series Modero Touch Panels
The Video Kits include the following components:
Modero VG-Series Touch Panel (NXD or NXT) (FG225X-XXV)
Modero 10’ foot Table Top Cable (CA2250-50)
NXA-AVB/ETHERNET Breakout Box (FG2254-10)
These panels are capable of displaying both Composite video and High-Definition Component RGB,
bringing together both Video and RGB capability together into one panel.
Modero Video/RGB-compatible panels utilize an internal NXA-RGB interface card (combined with an
external NXA-AVB/RGB Breakout Box) to accept and display high-bandwidth and high-quality RGB and
HDTV Component video signals. An existing Video Kit fitted VG-Series touch panel (Video only) can
be upgraded to display RGB input by purchasing a separate NXA-RGBKIT. These Video/RGB panels
include those listed below:
The RGB Kits include the following components:
Modero VG-Series Touch Panel (NXD or NXT) (FG225X-XXRGB)
NXA-AVB/RGB Breakout Box (FG2254-11)
NXA-RGB internal RGB/VGA Interface Card (FG2260) (pre-installed)
NXA-MTC/RGB Modero 10’ foot Table Top Cable (with RGB connector) (CA2250-70)
NXA-RGBCBL, 15-pin to 5X BNC RGB Breakout cable (FG2250-80)
Product Specifications (NXD-1200VG and NXT-1200VG)
The following table outlines the specifications for VG-Series of 12" Modero panels.
Modero Multimedia Touch Panels (VG-Series with RGB Kits)
NXD-1200VG (FG2251-61RGB) 12" Modero Multimedia WallMount Touch Panel with RGB Kit.
NXT-1200VG (FG2250-61RGB) 12" Modero Multimedia Table Top Touch Panel with RGB Kit.
NXD-1500VG (FG2253-61RGB) 15" Modero Multimedia WallMount Touch Panel with RGB Kit.
NXT-1500VG (FG2252-61RGB) 15" Modero Multimedia Table Top Touch Panel with RGB Kit.
NXD-1700VG (FG2256-61RGB) 17" Modero Widescreen WallMount Touch Panel with RGB Kit.
NXT-1700VG (FG2257-61RGB) 17" Modero Widescreen Table Top Touch Panel with RGB Kit.
1200VG Panel Specifications
Dimensions (HWD): • NXD-1200VG (with faceplate): 12.38" x 12.59" x 3.25"
(31.43 cm x 31.97 cm x 8.25 cm)
• NXT-1200VG (Fully raised): 10.91" x 12.34" x 12.50"
(27.70 cm x 31.33 cm x 31.75 cm)
• NXT-1200VG (Fully lowered): 6.77" x 12.34" x 12.50"
(17.20 cm x 31.33 cm x 31.75 cm)
• CB-TP12 (conduit/wallbox): 11.52" x 11.60" x 3.50"
(29.27 cm x 29.47 cm x 8.89 cm)
• MB-TP12 (VESA mounting box): 12.37" x 12.58" x 3.52"
(31.42 cm x 31.95 cm x 8.94 cm)
Power Requirements: • Constant current draw: 2.3 A @ 12 VDC (stand-alone)
• Startup current draw: 3.5 A @ 12 VDC (stand-alone)
Memory (factory default): • 256 MB on-board memory
• 128 MB Compact Flash (upgradeable to 1 GB factory programmed)
Weight: • NXD-1200VG: 10.80 lbs (4.90 kg)
• NXT-1200VG: 10.80 (4.90 kg)
