Firmware Pages and Descriptions
148
VG-Series Modero Touch Panels
Video Adjustment - Streaming Adjustment Page
The Streaming Video Adjustment page (FIG. 110) (accessed by pressing the Video Adjustment button on
the Setup page and then selecting the appropriate button from the option bar) adjusts the Video
properties of the incoming MPEG video streaming from the external content server.
Refer to the Displaying Stream Content section on page 169 for the procedures used to configure the
TPD4 touch panel pages and media stream source (using MAX-CSE for example purposes).
The elements of the Streaming Video Adjustment page are described in the table below:
FIG. 114 Streaming Video Adjustment page (showing default values)
Streaming Video Adjustment Page Elements
Back: Saves the changes and returns you to the previously active touch panel page.
Connection Status icon: This visual display of the connection status allows the user to have a current
visual update of the panel’s connection status regardless of what page is
currently active.
• A Lock only appears on the icon if the panel has established a connection
with a currently secured target Master (requiring a username and password).
Settings: • The Default Settings button sets the streaming video settings to their default
values (indicated in this table).
• The Undo Changes button disregards any changes made on the page since
the last settings were saved.
• The Save Settings button saves any changes made to the Video Setup page.
Video Settings: • The Sharpness button toggles the Interpolate (Sharpness) feature.
Default = On.
•The Interlace button toggles the Interlacing feature.
Default = On.
Incoming Streaming Video signal
