Firmware Pages and Descriptions
144
VG-Series Modero Touch Panels
RGB Adjustment Page Elements (Cont.)
All Brightness: Provides an on-screen RGB Brightness popup dialog that allows you to select
from several brightness level adjustment settings.The bargraph only serves to
give the user a visual indication of the individual brightness levels and launch
the RGB Brightness popup dialog.
Use the UP/DN buttons to alter the overall RGB brightness levels of the
NXA-RGB card.
• Press the All Brightness bargraph to open the RGB Brightness popup
dialog.
• Use the Hide button to close the popup.
• Range = 0 - 255.
Red Brightness Use the slider bar to alter the brightness of the red color value.
• Range = 0 - 255, default = 115.
• For more accurate control, you will have to go into the Full Screen Edit Mode
described in the following section.
Green Brightness Use the slider bar to alter the brightness of the green color value.
• Range = 0 - 255, default = 120.
• For more accurate control, you will have to go into the Full Screen Edit Mode
described in the following section.
Blue Brightness Use the slider bar to alter the brightness of the blue color value.
• Range = 0 - 255, default = 100.
• For more accurate control, you will have to go into the Full Screen Edit Mode
described in the following section.
All Contrast: Provides an on-screen RGB Contrast popup dialog that allows you to select
from several contrast level adjustment settings. The bargraph only serves to
give the user a visual indication of the individual contrast levels and launch the
RGB Contrast popup dialog.
Use the UP/DN buttons to alter the overall RGB contrast levels of the
NXA-RGB card.
• Press the All Brightness bargraph to open the RGB Brightness popup
dialog.
• Use the Hide button to close the popup.
• Range = 0 - 255.
Red Contrast Use the slider bar to alter the contrast of the red color value.
• Range = 0 - 255, default = 60.
• For more accurate control, you will have to go into the Full Screen Edit Mode
described in the following section.
Green Contrast Use the slider bar to alter the contrast of the green color value.
• Range = 0 - 255, default = 60.
• For more accurate control, you will have to go into the Full Screen Edit Mode
described in the following section.
Blue Contrast Use the slider bar to alter the contrast of the blue color value.
• Range = 0 - 255, default = 60.
• For more accurate control, you will have to go into the Full Screen Edit Mode
described in the following section.
