10 PAD LAYOUT
A-90 EPSON S1C33210 PRODUCT PART
No. Pad name X Y No. Pad name X Y
101 N.C. 2.834 1.554 151 N.C. -1.26 2.54
102 P35/#BUSACK 2.834 1.638 152 VSS -1.344 2.54
103 #HCAS 2.834 1.722 153 N.C. -1.428 2.54
104 #LCAS 2.834 1.806 154 A19 -1.512 2.54
105 P34/#BUSREQ/#CE6 2.834 1.89 155 N.C. -1.596 2.54
106 N.C. 2.834 1.974 156 P20/#DRD -1.68 2.54
107 A4 2.834 2.058 157 N.C. -1.764 2.54
108 A5 2.352 2.54 158 VDD -1.848 2.54
109 N.C. 2.268 2.54 159 N.C. -1.932 2.54
110 A6 2.184 2.54 160 RTS -2.016 2.54
111 A7 2.1 2.54 161 DTR -2.1 2.54
112 VSS 2.016 2.54 162 DSR -2.184 2.54
113 N.C. 1.932 2.54 163 N.C. -2.268 2.54
114 P30/#WAIT/#CE4&5 1.848 2.54 164 RI -2.352 2.54
115 N.C. 1.764 2.54 165 CNT2 -2.834 2.058
116 A8 1.68 2.54 166 N.C. -2.834 1.974
117 N.C. 1.596 2.54 167 CNT1 -2.834 1.89
118 A9 1.512 2.54 168 TXD/SOUT3 -2.834 1.806
119 N.C. 1.428 2.54 169 CTS -2.834 1.722
120 #CE5/#CE15/#CE15&16 1.344 2.54 170 N.C. -2.834 1.638
121 N.C. 1.26 2.54 171 VSS -2.834 1.554
122 A10 1.176 2.54 172 PLLC -2.834 1.47
123 N.C. 1.092 2.54 173 N.C. -2.834 1.386
124 A20 1.008 2.54 174 N.C. -2.834 1.302
125 N.C. 0.924 2.54 175 VSS -2.834 1.218
126 VDD 0.84 2.54 176 N.C. -2.834 1.134
127 N.C. 0.756 2.54 177 PLLS1 -2.834 1.05
128 A11 0.672 2.54 178 N.C. -2.834 0.966
129 N.C. 0.588 2.54 179 PLLS0 -2.834 0.882
130 A21 0.504 2.54 180 N.C. -2.834 0.798
131 N.C. 0.42 2.54 181 RXD/SIN3 -2.834 0.714
132 P16/EXCL5/#DMAEND1 0.336 2.54 182 DCD -2.834 0.63
133 A12 0.252 2.54 183 N.C. -2.834 0.546
134 A22 0.168 2.54 184 MSEL -2.834 0.462
135 TST 0.084 2.54 185 N.C. -2.834 0.378
136 N.C. 0 2.54 186 GOUT -2.834 0.294
137 A13 -0.084 2.54 187 N.C. -2.834 0.21
138 A23 -0.168 2.54 188 VDD -2.834 0.126
139 P04/SIN1 -0.252 2.54 189 N.C. -2.834 0.042
140 A14 -0.336 2.54 190 OSC3 -2.834 -0.042
141 N.C. -0.42 2.54 191 N.C. -2.834 -0.126
142 A15 -0.504 2.54 192 OSC4 -2.834 -0.21
143 N.C. -0.588 2.54 193 N.C. -2.834 -0.294
144 P05/SOUT1 -0.672 2.54 194 EA10MD0 -2.834 -0.378
145 N.C. -0.756 2.54 195 EA10MD1 -2.834 -0.462
146 A16 -0.84 2.54 196 #X2SPD -2.834 -0.546
147 N.C. -0.924 2.54 197 N.C. -2.834 -0.63
148 A17 -1.008 2.54 198 P21/#DWE/#GAAS -2.834 -0.714
149 N.C. -1.092 2.54 199 N.C. -2.834 -0.798
150 A18 -1.176 2.54 200 P22/TM0 -2.834 -0.882
