February 2002 © TOSHIBA TEC 2 - 19 FC-210/310 ADJUSTMENT
The following adjustments (c) to (g) should be conducted using Test Chart No. TCC-1. (Refer to page 2-
22.)
(c) Reproduction ratio adjustment of primary-scanning (Scanner section)
1. While pressing the digital keys [0] and [5] simultaneously, turn the power ON. ৎ (Adjustment mode)
2. Place Test Chart No. TCC-1 on the original glass (with the arrow positioned at the left rear side).
3. Press [ENERGY SAVER] ৎ [START] to make a copy in the mode of A4/LT, 100%, full color and text/
photo.
4. Measure the distance A between M1 and M2 on the copy with a ruler.
5. Check if the distance A is within a range of 200±0.5 mm or not.
6. If it is not, change values using the following procedure, and repeat step 3. to 5. above.
<Procedure> (Adjustment mode) ৎ (Enter code [482] with digital keys) ৎ [START]
ৎ (Enter a value (acceptable values : 112 to 142) with digital keys)
ৎ [SET] or [INTERRUPT] (Stored in memory)
ৎ (Enter code [407] with digital keys) ৎ [START]
ৎ Forced performing of color registration control
* The larger the adjustment value, the shorter the distance A becomes (0.2 mm/step).
(d) Reproduction ratio adjustment of secondary-scanning (Scanner section)
1. While pressing the digital keys [0] and [5] simultaneously, turn the power ON. ৎ (Adjustment mode)
2. Place Test Chart No. TCC-1 on the original glass (with the arrow positioned at the left rear side).
3. Press [ENERGY SAVER] ৎ [START] to make a copy in the mode of A4/LT, 100%, full color and text/
photo.
4. Measure the distance B between M3 and M4 on the copy with a ruler.
5. Check if the distance B is within a range of 150±0.5 mm or not.
6. If it is not, change values using the following procedure, and repeat step 3. to 5. above.
<Procedure> (Adjustment mode) ৎ (Enter code [104] with digital keys) ৎ [START]
ৎ (Enter a value (acceptable values : 1 to 255) with digital keys)
ৎ [SET] or [INTERRUPT] (Stored in memory)
ৎ (Enter code [407] with digital keys) ৎ [START]
ৎ Forced performing of color registration control
* The larger the adjustment value, the longer the distance B becomes(0.23 mm/step).
