Appendix A: Specifications
295
Digital CIM Display Native Resolution
You are able to select the native resolution of the CIM on the Port
Configuration page from the Display Native Resolution drop-down.
This is the preferred resolution and timing mode of the digital CIM. Once
a resolution is selected, it is applied to the CIM.
If no selection is made, the default 1024x1280@60Hz resolution is used.
See Configuring CIM Ports (on page 176)
DVI Compatibility Mode
DVI Compatibility Mode may be required if you are using an HDMI CIM
to connect to a Dell Optiplex target with an Intel video card, or a Mac
®
Mini with an HDMI video port.
Selecting this mode ensures a good video quality from the targets.
See Configuring CIM Ports (on page 176) in online help.
Digital Video CIMs for Macs
Use a digital video CIM to connect to the following Mac
®
ports:
Mac port
CIM
DVI
D2CIM-DVUSB-DVI
HDMI
D2CIM-DVUSB-HDMI
DisplayPort or Thunderbolt
D2CIM-DVUSB-DP
If the Mac’s HDMI or DisplayPort video has a mini connector, a passive
adapter cable may be required to connect to the full sized HDMI and
DisplayPort plugs on the digital CIMs.
Alternatively, use the Mac VGA adapter with the D2CIM-VUSB or
D2CIM-DVUSB. Note that this may be less reliable and the video quality
may suffer.
For information on established modes supported by the KX II 2.5.0 (and
later) for Mac, see Digital CIM Established and Standard Modes (on
page 294).
