3-23
Configuration Menu
Map Inputs Menu
The Map Inputs Menu allows assignment of video, key, and
chroma key inputs to crosspoints. Includes shaped/unshaped
selection for video and key inputs.
Select the crosspoint button column to be assigned by pressing the
PST button in that column.
The Map Inputs Menu selections are as follows:
VIDEO/KEY FMT — Selects Shaped or Unshaped format for the
selected video or key signal.
LOG/PHYS ASSIGNMENT — Allows a poolable DPM (such as
Kaleidoscope) to control its logical channels (video and key)
connected to the Model 3000.
LOG CHANNEL — Selects the mode used to assign logical
channels from a poolable DPM to crosspoints.
PHYS INPUTS — Selects the mode used when assigning any
inputs that are not controlled by a poolable DPM.
MAP INPUTS MENU
SHAPED
VIDEO
config / inputs / map inputs
VIDEO/
KEY FMT
CHROMA KEY INPUT
= NONE
(ENCODED)
VIDEO INPUT
= DPM 1 LOG CHAN 1
(KSCOPE)
KEY INPUT
= DPM 1 LOG CHAN 1
(KSCOPE)
NAME XPT
BUTTON >
LOG/PHYS
ASSIGNMENT
UNSHAPED
VIDEO
PHYS INPUTS
LOG CHANNEL
12
XPT BUTTON
NUMBER
XPT BUTTON
NAME
Use the Preset Bus to select button number.
