Section 3 — Menu Descriptions
Aux Bus Format Menu
This menu is used to set up the format for each of the 7 aux buses.
Each bus consists of an “A” bus and a “B” bus. The “A” buses are
for video only. The “B” buses may be either video or key.
AUX BUS 1B through AUX BUS 7B — Selects either VIDEO or KEY
for each “B” aux bus.
Make sure that any aux buses assigned to Kaleidoscope are
configured for KEY operation of their “B” aux buses.
NOTE:
Shaping of the outputs for Aux Buses 1-4 may be done in the
Config/Outputs Menu.
AUX BUS FORMAT MENU
config / aux bus format
KEY KEY KEY KEY KEY
VIDEO VIDEO
VIDEO
AUX
BUS 1B
VIDEO
AUX
BUS 2B
VIDEO
AUX
BUS 3B
VIDEO
AUX
BUS 4B
VIDEO
AUX
BUS 5B
AUX
BUS 6B
KEY
AUX
BUS 7B
KEY
