3-106
Section 3 — Menu Descriptions
STROBE—When
ON
is selected, strobe is activated. Strobe
alternates between a frozen framestore image and a selected
source image (M/E, PGM, etc. delegated to Aux Bus 4) with the
frequency set by the soft knobs described below. The difference
between the time settings is what varies the strobe effect.
STROBE TIME PERIOD — Sets the time (in fields) for the
delegated video source to be displayed. Minimum time
period is 4 fields.
STROBE FREEZE PERIOD
— Sets the time (in fields) during
which the frozen frame store image is displayed. Minimum
time period is 8 fields.
PAGE SELECT —Selects one of four pages (frames) of the video
image.
MOSAIC> — Opens the Video Store Mosaic Menu.
PSEUDOCOLOR> — Opens the Video Store Pseudo Color Menu.
CROP>
— Opens the Video Store Crop Menu.
REPOSITION>
— Opens the Video Store Reposition Menu.
FILTER>
— Opens the Video Store Filter Menu.
NOTE:
The Mosaic, Pseudo Color, and Filter modes are functional only
in 2-field mode.
