E-MEM CONTROL — MISC activates E-MEM recalls at the MISC or
DPM
level for the selected aux bus, depending on the level
selection in the Config/External IF/DPM Setup/Map Aux Buses
Menu. OFF disables E-MEM recalls for the selected bus.
NEAR/FAR/BOTH — These buttons determine whether the video
source for the currently-highlighted aux bus will appear on the
near side, the far side, or both. If you visualize a rotating card with
an image on the front and an image on the back, the image that
you can see at this moment is the near side, and the image hidden
on the back is the far side.
TAKE — Changes the source selection for the currently-selected
aux bus. Sources can also be changed by selecting them on the Aux
Bus or the Remote Aux Panel.
Mask Menu
The Mask Menu allows you to adjust the opacity of the inhibit
mask and to set chroma filtering.
ON
ON
OFF
ON
OFF
OFF
M/E1 KEY1
M/E2 KEY1
M/E2 KEY2
M/E3 KEY1
M/E3 KEY2
MASK MENU
mask
INH MASK
OPACITY
KEYER
SELECT
MASK BUS
CHR TRAP
INHIBIT MASK OPACITY
= 100%
M/E1 KEY2 ON
ON
OFFM/E1 KEY2
ON
OFF
