S3C2440A RISC MICROPROCESSOR PRODUCT OVERVIEW
1-11
Table 1-2. S3C2440A 289-Pin FBGA Pin Assignments (Sheet 2 of 9)
Pin
Number
Pin
Name
Default
Function
I/O State
@BUS REQ
I/O State
@Sleep
I/O State
@nRESET
I/O Type
P16 XP/AIN7 XP –/– –/– AI r10
H6 CAMDATA0/GPJ0 GPJ0 –/– Hi-z/– I t8
G3 CAMDATA1/GPJ1 GPJ1 –/– Hi-z/– I t8
H5 CAMDATA2/GPJ2 GPJ2 –/– Hi-z/– I t8
H4 CAMDATA3/GPJ3 GPJ3 –/– Hi-z/– I t8
H3 CAMDATA4/GPJ4 GPJ4 –/– Hi-z/– I t8
H7 CAMDATA5/GPJ5 GPJ5 –/– Hi-z/– I t8
J8 CAMDATA6/GPJ6 GPJ6 –/– Hi-z/– I t8
H2 CAMDATA7/GPJ7 GPJ7 –/– Hi-z/– I t8
G5 CAMPCLK/GPJ8 GPJ8 –/– Hi-z/– I t8
G7 CAMVSYNC/GPJ9 GPJ9 –/– Hi-z/– I t8
G2 CAMHREF/GPJ10 GPJ10 –/– Hi-z/– I t8
J3 CAMCLKOUT/GPJ11 GPJ11 –/– O(L)/– I t8
J4 CAMRESET/GPJ12 GPJ12 –/– O(L)/– I t8
D12 DATA0 DATA0 Hi-z Hi-z,O(L) I b12s
C12 DATA1 DATA1 Hi-z Hi-z,O(L) I b12s
E11 DATA2 DATA2 Hi-z Hi-z,O(L) I b12s
A13 DATA3 DATA3 Hi-z Hi-z,O(L) I b12s
F10 DATA4 DATA4 Hi-z Hi-z,O(L) I b12s
F11 DATA5 DATA5 Hi-z Hi-z,O(L) I b12s
C13 DATA6 DATA6 Hi-z Hi-z,O(L) I b12s
A14 DATA7 DATA7 Hi-z Hi-z,O(L) I b12s
D13 DATA8 DATA8 Hi-z Hi-z,O(L) I b12s
B15 DATA9 DATA9 Hi-z Hi-z,O(L) I b12s
A17 DATA10 DATA10 Hi-z Hi-z,O(L) I b12s
C14 DATA11 DATA11 Hi-z Hi-z,O(L) I b12s
D15 DATA12 DATA12 Hi-z Hi-z,O(L) I b12s
C15 DATA13 DATA13 Hi-z Hi-z,O(L) I b12s
D14 DATA14 DATA14 Hi-z Hi-z,O(L) I b12s
B17 DATA15 DATA15 Hi-z Hi-z,O(L) I b12s
C16 DATA16 DATA16 Hi-z Hi-z,O(L) I b12s
E15 DATA17 DATA17 Hi-z Hi-z,O(L) I b12s
E14 DATA18 DATA18 Hi-z Hi-z,O(L) I b12s
