LCD CONTROLLER S3C2440A RISC MICROPROCESSOR
15-32
LCD Control 5 Register (Continued)
LCDCON5 Bit Description Initial state
INVVDEN [6]
TFT: This bit indicates the VDEN signal polarity.
0 = normal 1 = inverted
0
INVPWREN [5]
STN/TFT: This bit indicates the PWREN signal polarity.
0 = normal 1 = inverted
0
INVLEND [4]
TFT: This bit indicates the LEND signal polarity.
0 = normal 1 = inverted
0
PWREN [3]
STN/TFT: LCD_PWREN output signal enable/disable.
0 = Disable PWREN signal 1 = Enable PWREN signal
0
ENLEND [2]
TFT: LEND output signal enable/disable.
0 = Disable LEND signal 1 = Enable LEND signal
0
BSWP [1]
STN/TFT: Byte swap control bit.
0 = Swap Disable 1 = Swap Enable
0
HWSWP [0]
STN/TFT: Half-Word swap control bit.
0 = Swap Disable 1 = Swap Enable
0
