THUMB INSTRUCTION SET S3C2440A RISC MICROPROCESSOR
4-24
FORMAT 10: LOAD/STORE HALFWORD
[2:0] Source/Destination Register
[5:3] Base Register
[10:6] Immediate Value
[11] Load/Store Flag
0 = Store to memory
1 = Load from memory
15 0
0
14
10
65
32
Rd
10
13 12
11
Rb
0 L Offset5
Figure 4-11. Format 10
OPERATION
These instructions transfer halfword values between a Lo register and memory. Addresses are pre-indexed, using
a 6-bit immediate value. The THUMB assembler syntax is shown in Table 4-11.
Table 4-11. Halfword Data Transfer Instructions
L THUMB assembler ARM equivalent Description
0 STRH Rd, [Rb, #Imm] STRH Rd, [Rb, #Imm] Add #Imm to base address in Rb and store
bits 0 - 15 of Rd at the resulting address.
1 LDRH Rd, [Rb, #Imm] LDRH Rd, [Rb, #Imm] Add #Imm to base address in Rb. Load bits
0-15 from the resulting address into Rd and
set bits 16-31 to zero.
NOTE
#Imm is a full 6-bit address but must be halfword-aligned (ie with bit 0 set to 0) since the assembler places
#Imm >> 1 in the Offset5 field.
