PRODUCT OVERVIEW S3C2440A RISC MICROPROCESSOR
1-30
Table 1-4. S3C2440A Special Registers (Sheet 4 of 14)
Register
Name
Address
(B. Endian)
Address
(L. Endian)
Acc.
Unit
Read/
Write
Function
Clock & Power Management
LOCKTIME 0x4C000000
←
W R/W PLL Lock Time Counter
MPLLCON 0x4C000004 MPLL Control
UPLLCON 0x4C000008 UPLL Control
CLKCON 0x4C00000C Clock Generator Control
CLKSLOW 0x4C000010 Slow Clock Control
CLKDIVN 0x4C000014 Clock divider Control
CAMDIVN 0x4C000018 Camera Clock divider Control
LCD Controller
LCDCON1 0X4D000000
←
W R/W LCD Control 1
LCDCON2 0X4D000004 LCD Control 2
LCDCON3 0X4D000008 LCD Control 3
LCDCON4 0X4D00000C LCD Control 4
LCDCON5 0X4D000010 LCD Control 5
LCDSADDR1 0X4D000014 STN/TFT: Frame Buffer Start
Address1
LCDSADDR2 0X4D000018 STN/TFT: Frame Buffer Start
Address2
LCDSADDR3 0X4D00001C STN/TFT: Virtual Screen Address Set
REDLUT 0X4D000020 STN: Red Lookup Table
GREENLUT 0X4D000024 STN: Green Lookup Table
BLUELUT 0X4D000028 STN: Blue Lookup Table
DITHMODE 0X4D00004C STN: Dithering Mode
TPAL 0X4D000050 TFT: Temporary Palette
LCDINTPND 0X4D000054 LCD Interrupt Pending
LCDSRCPND 0X4D000058 LCD Interrupt Source
LCDINTMSK 0X4D00005C LCD Interrupt Mask
TCONSEL 0X4D000060 TCON(LPC3600/LCC3600) Control
