PRODUCT OVERVIEW S3C2440A RISC MICROPROCESSOR
1-32
Table 1-4. S3C2440A Special Registers (Sheet 6 of 14)
Register
Name
Address
(B. Endian)
Address
(L. Endian)
Acc.
Unit
Read/
Write
Function
Camera Interface
CISRCFMT 0x4F000000
←
W RW Input Source Format
CIWDOFST 0x4F000004
Window offset register
CIGCTRL 0x4F000008
Global control register
CICOYSA1 0x4F000018
Y 1
st
frame start address for codec DMA
CICOYSA2 0x4F00001C
Y 2
nd
frame start address for codec DMA
CICOYSA3 0x4F000020
Y 3
rd
frame start address for codec DMA
CICOYSA4 0x4F000024
Y 4
th
frame start address for codec DMA
CICOCBSA1 0x4F000028
Cb 1
st
frame start address for codec DMA
CICOCBSA2 0x4F00002C
Cb 2
nd
frame start address for codec DMA
CICOCBSA3 0x4F000030
Cb 3
rd
frame start address for codec DMA
CICOCBSA4 0x4F000034
Cb 4
th
frame start address for codec DMA
CICOCRSA1 0x4F000038
Cr 1
st
frame start address for codec DMA
CICOCRSA2 0x4F00003C
Cr 2
nd
frame start address for codec DMA
CICOCRSA3 0x4F000040
Cr 3
rd
frame start address for codec DMA
CICOCRSA4 0x4F000044
Cr 4
th
frame start address for codec DMA
CICOTRGFMT 0x4F000048
Target image format of codec DMA
CICOCTRL 0x4F00004C
Codec DMA control related
CICOSCPRERATIO 0x4F000050
Codec pre-scaler ratio control
CICOSCPREDST 0x4F000054
Codec pre-scaler destination format
CICOSCCTRL 0x4F000058
Codec main-scaler control
CICOTAREA 0x4F00005C
Codec scaler target area
CICOSTATUS 0x4F000064
Codec path status
CIPRCLRSA1 0x4F00006C
RGB 1
st
frame start address for preview DMA
CIPRCLRSA2 0x4F000070
RGB 2
nd
frame start address for preview DMA
CIPRCLRSA3 0x4F000074
RGB 3
rd
frame start address for preview DMA
CIPRCLRSA4 0x4F000078
RGB 4
th
frame start address for preview DMA
CIPRTRGFMT 0x4F00007C
Target image format of preview DMA
CIPRCTRL 0x4F000080
Preview DMA control related
CIPRSCPRERATIO 0x4F000084
Preview pre-scaler ratio control
CIPRSCPREDST 0x4F000088
Preview pre-scaler destination format
CIPRSCCTRL 0x4F00008C
Preview main-scaler control
CIPRTAREA 0x4F000090
Preview scaler target area
CIPRSTATUS 0x4F000098
Preview path status
CIIMGCPT 0x4F0000A0
Image capture enable command
