IIC-BUS INTERFACE S3C2440A RISC MICROPROCESSOR
20-12
MULTI-MASTER IIC-BUS CONTROL/STATUS (IICSTAT) REGISTER
Register Address R/W Description Reset Value
IICSTAT 0x54000004 R/W IIC-Bus control/status register 0x0
IICSTAT Bit Description Initial State
Mode selection [7:6] IIC-bus master/slave Tx/Rx mode select bits.
00 : Slave receive mode
01 : Slave transmit mode
10 : Master receive mode
11 : Master transmit mode
00
Busy signal status /
START STOP condition
[5] IIC-Bus busy signal status bit.
0 : read) Not busy (when read)
write) STOP signal generation
1 : read) Busy (when read)
write) START signal generation.
The data in IICDS will be transferred
automatically just after the start signal.
0
Serial output [4] IIC-bus data output enable/disable bit.
0 : Disable Rx/Tx, 1 : Enable Rx/Tx
0
Arbitration status flag [3] IIC-bus arbitration procedure status flag bit.
0 : Bus arbitration successful
1 : Bus arbitration failed during serial I/O
0
Address-as-slave status flag [2] IIC-bus address-as-slave status flag bit.
0 : Cleared when START/STOP condition was
detected
1 : Received slave address matches the address
value in the IICADD
0
Address zero status flag [1] IIC-bus address zero status flag bit.
0 : Cleared when START/STOP condition was
detected
1 : Received slave address is 00000000b.
0
Last-received bit status flag [0] IIC-bus last-received bit status flag bit.
0 : Last-received bit is 0 (ACK was received).
1 : Last-received bit is 1 (ACK was not received).
0
