S3C2440A RISC MICROPROCESSOR LCD CONTROLLER
15-17
MEMORY DATA FORMAT (TFT)
This section includes some examples of each display mode.
24BPP Display
(BSWP = 0, HWSWP = 0, BPP24BL = 0)
D[31:24] D[23:0]
000H Dummy Bit P1
004H Dummy Bit P2
008H Dummy Bit P3
...
(BSWP = 0, HWSWP = 0, BPP24BL = 1)
D[31:8] D[7:0]
000H P1 Dummy Bit
004H P2 Dummy Bit
008H P3 Dummy Bit
...
P1 P2 P3 P4 P5
......
LCD Panel
VD Pin Descriptions at 24BPP
VD 23 22 21 20 19 18 17 16151413121110987 6 5 4 3210
RED 7 6 5 4 3 2 1 0
GREEN 76543210
BLUE 7 6 5 4 3210
