Showing PNNI Information
407
Local Port The number of the local port that connects to the
remote port.
Remote Port The number of the remote port that connects to the
local port.
Remote Node The node ID of the remote port.
Table 52 PTSE Table Parameters - Node Address Section
Parameter Description
Address prefix The address of node within the peer group.
Length The number of significant bits of the ATM address that
are used for route calculation.
Node The address of the node that originated the PTSE.
Table 53 PTSE Table Parameters - Peer Group Neighbor Table Section
Parameter Description
Remote Node Id The node ID of the remote port.
State The operational status of the link between the two
neighbor nodes. The state may be: Full, Up, Down,
Negotiating, Exchanging, Loading or Unknown.
Port Count The number of ports via which two neighbors
connect.
Table 54 PTSE Table Parameters - Summary Address Table Section
Parameter Description
SNMP Node Index The node index.
Internal Summaries
Address
The reachable address prefix for all nodes in a
specified peer group.
Length The number of significant bits of the specific summary
ATM address that are used for route calculation.
Supp Indicates whether or not to suppress the address. No
propagates the address to the peer group, Yes does
not advertise the address.
State Indicates whether or not the summary address is
currently being advertised to the peer group. The state
may be: Advertising, Suppressing or Inactive.
Table 51 PTSE Table Parameters - Node Topology Link Section (continued)
Parameter Description
