Adding or Removing Cabinet Hardware
6-47Add IP Interface Assembly
6
3. Read and follow any directions inserted into the package by the factory.
The TN802B external cable assembly is a bundle of cables with an amphenol
connector at the end of the bundle and various PC-type connectors (VGA,
Universal Serial Bus [USB], mouse, keyboard, Ethernet, modem, and COM2) at
the ends of the individual cables. See Figure 6-20
. Look for the label where the
bundle enters the amphenol connector.
Table 6-4. Required Hardware
Comcode/Code Description Quantity
108525528 TN799B C-LAN circuit pack. One
TN799B supports more than one
TN802B.
1
J58890MA-1 L30 TN802B IP Interface Assembly
1 or more
601939804 H600-512,G1 external cable assembly 1 or more
259A connector 1
CAT5 or better cable 1
407633999 U.S. Robotics Sportster external
modem, Model USR 33.6 EXT (U.S.
customers only). Non-U.S. customers
must provide a modem comparable to
this model.
1
601087091 20-ft DB-25 serial cable from modem
to TN802B external cable assembly
(U.S. customers only). Non-U.S.
customers must provide a serial cable.
1
