Chapter 5 Volume Management
5.2 Functions in the Action Area for Volume
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
103
• Encryption by CM
Select whether to encrypt (On) or not encrypt (Off) the new volumes. When the encryption mode is
disabled, "On" cannot be selected.
• Number of Volumes (When creating volumes other than "TPV")
Specify the number of volumes that is to be created in each RAID group between "1" and "128".
Click the [Recalculation of Max Count] button to display the maximum number of volumes that can
be created in each RAID group with the specified capacity. When the volume capacity is not speci-
fied (including when "Use all Largest Free Space" is selected), the maximum number of volumes
that can be created for each RAID group is displayed. When "Encryption by CM" is "On", volumes can-
not be created in the RAID groups for which "Disk Type" is "SED".
• Number of Volumes (When creating "TPV")
Specify the number of volumes that is to be created in each TPP between "1" and "16384".
→ A confirmation screen appears.
An existing volume number cannot be specified.
When creating a volume (when specifying "1" or more for "Number of Volumes") in the RAID group
for which "Disk Type" is "SED", select "Off" for this item.
When volume numbers are manually specified, only one volume can be created at a time. Input
"1" for "Number of Volumes".
• When using the ETERNUS DX8700 S2, up to 1024 volumes can be created at a time.
• When volume numbers are manually specified, only one volume can be created at a time.
Input "1" for "Number of Volumes".
