Chapter 7 Thin Provisioning Pool Management
7.2 Functions in the Action Area for Thin Provisioning
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
243
ECO Mode Schedule Setting
ECO Mode General Setting
Enabled Disabled
Control
Status
ON
During
scheduled
event term
Disk motor is activated. (ECO mode is running) Disk motor runs
regardless of
schedule
settings. (ECO
mode is not
running)
Times other
than scheduled
event term
Disk motor is stopped. (ECO mode is running)
If the RAID group is accessed, disk motors are activated within
1 - 5 minutes.
OFF
The target disk motor is operating constantly. (ECO mode is
not running)
Schedule is not applied Disk motor is operating constantly. (ECO mode is not running)
Disks not registered in the TPPs Disk motor is stopped constantly. (ECO mode is running)
Before applying ECO mode for TPPs, use the procedure in "11.2.8.1 Modify ECO Mode General Setting"
(page 869) to enable the ECO mode setting for the ETERNUS DX Disk storage system.
Set the ECO mode schedule using the procedure in "11.2.8.4 Modify ECO Mode Schedule" (page 876)
.
This function cannot be used under the following conditions:
- No volumes are created
- Configured by SSDs
When using ECO mode, make sure to set the time/date correctly. If the time/date of the ETERNUS DX Disk
storage system is wrong, processes used for stopping and starting the disk motor cannot be performed
per the ECO mode schedule.
If any of the following conditions occur during the ECO mode scheduled time, the disk will be started even
when the disk motor is inactive. Note that the ECO mode schedule will be re-enabled when the following
conditions have finished.
- When the target TPP status is not " Available"
- When performing functions that change the TPP or the volume configuration
- When performing rebuild or copyback in the RAID groups that configure the target TPP
- When formatting is being performed in the TPP
- When RAID migration is being performed in the volumes registered in the TPP
- When Advanced Copy is being performed in the volume registered in the TPP (copy session status is
not "Suspend" or "Tracking")
- During maintenance
- When performing disk diagnosis, TPP diagnosis (diagnosing the RAID groups that configure the TPP),
or when exporting G-List
- When a module error related to the access paths of the Controller Modules and drives is detected
When the ECO mode is set to TPP, the same ECO Mode schedule is set for all the RAID groups configuring
the TPP.
When selecting multiple TPPs as the target of the ECO mode, the same ECO mode schedule can be
specified for all the selected TPPs.
