Chapter 11 System Management
11.2 Functions in the Action Area for System
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
772
The procedure to set the SNMP Agent community is as follows:
Procedure
1 Click [Setup SNMP Community] in [Action].
2 Click the [Add] button.
3 Input or edit the community, and click the [OK] button.
• Community Name
Input the community name to be used when accessing a MIB or sending a trap.
The community name which has already been used cannot be entered.
The following input conditions apply:
- Up to 32 alphanumeric characters and symbols
- "! (exclamation mark)", "# (hash mark)", "& (ampersand)", "_ (underscore)", "+ (plus)", "-
(hyphen)", "* (asterisk)" and "/ (slash)" can be used
- Spaces
• View Name
Select the view name to specify the MIB access range for the community.
A "blank" means accessing the MIB is not allowed.
The SNMP Managers which are allowed to access, and the MIB access range, can be specified for each
community.
Click the [Community Name] link to edit the existing community information.
