Chapter 10 Component Management
10.1 Component Status
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
637
- For ETERNUS DX8100 S2/DX8700 S2
• 8G-FC 2port
• 8G-FC 4port
• 16G-FC 2port
• 16G-FC 4port
• 10G-iSCSI 2port
• 1G-iSCSI 2port
• 10G-FCoE 2port
• 1G-iSCSI-RA 2port
• Status
The CA status is displayed. Refer to "B.5 Component Status" (page 977)
for details.
10.1.2.4 Channel Adapter Ports (Performance)
The CA port performance information is displayed.
The 1-port type CA provided by ETERNUS DX80 S2 is also displayed as a 2-port type. To determine
whether the CA is 1-port type or 2-port-type, refer to the port number displayed in the [Internal Parts]
tab in the "10.1.6 Channel Adapter Detail" (page 655)
. Note that 1-port type CAs are not available in
some regions.
When the port mode is "Initiator", the CA port performance is not displayed.
• Performance information is obtained when performance monitoring is operated from GUI, CLI, or any
other monitoring software. Refer to "11.2.12.4 Start/Stop Performance Monitoring" (page 925)
for details
on how to start performance monitoring with GUI.
• The interval for acquiring performance information can be specified when starting the monitoring. When
using GUI, the default interval is 30 seconds.
• The average performance values during the specified interval are displayed.
