Chapter 6 RAID Group Management
6.1 RAID Group Status
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
166
• Usage
The usage of the RAID group is displayed.
- Standard
A RAID group that is used for creating "Standard", "SDV", or "SDPV" type volumes
- Standard / WSV
A RAID group that is used for creating "Standard", "WSV", "SDV", or "SDPV" type volumes
- WSV
A RAID group that is used for creating "WSV" type volumes
• RAID Type
The type of RAID group is displayed.
- High Performance (RAID1+0)
- High Capacity (RAID5)
- High Reliability (RAID6)
- Reliability (RAID5+0)
- Mirroring (RAID1)
- Striping (RAID0)
• Total Capacity
The total capacity of the RAID groups is displayed.
• ECO Mode Schedule
The ECO mode schedule name that is applied for the RAID group is displayed. When the ECO mode
schedule is not applied, the field is blank.
• ECO Mode Action
When the ECO mode is enabled, "ON" is displayed. When the ECO mode is disabled, "OFF" is displayed.
• Motor Status
The disk motor status for the RAID group is displayed.
- Active
The disk motors are activated.
- In the Boot Process
The disk motors are starting up.
- Idle
The disk motors are stopped.
- In the Stop Process
The disk motors are being stopped.
Filter setting
Filter Description
Name
Input the RAID group name that is to be displayed.
When not using the RAID group name for filtering, leave this item blank.
Status Select the RAID group status that is to be displayed.
RAID Type Select the RAID type that is to be displayed.
ECO Mode Schedule
Input the ECO mode schedule name that is applied to the RAID group that is to be
displayed.
When not using the ECO mode schedule name for filtering, leave this item blank.
ECO Mode Action
Select the operating status of the ECO mode that is applied to the RAID group status that
is to be displayed.
