Chapter 10 Component Management
10.1 Component Status
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
654
The following items are displayed in the Main area:
• Parts
The component name and the component number are displayed.
A link is displayed for the ETERNUS DX80 S2/DX90 S2, the ETERNUS DX410 S2/DX440 S2, or the ETERNUS
DX8100 S2 when the "Parts" is "QSFP Cable". Click this link to display the [QSFP Cable] screen. Refer to
"10.1.18 QSFP Cable Detail" (page 678)
for display items.
A link is displayed for the ETERNUS DX8100 S2/DX8700 S2 when the "Parts" is "BUD". Click this link to dis-
play the [Boot and Utility Device] screen. Refer to "10.1.19 Boot and Utility Device Detail" (page 679)
for
display items.
A link is displayed for the ETERNUS DX8700 S2 when the "Parts" is "CA". Click this link to display the [Chan-
nel Adapter] screen. Refer to "10.1.6 Channel Adapter Detail" (page 655)
for display items.
A link is displayed for the ETERNUS DX8700 S2 when the "Parts" is "CM MMC". Click this link to display the
[CM Module Management Controller] screen. Refer to "10.1.20 CM Module Management Controller Detail"
(page 680) for display items.
• Status
The component status is displayed. Refer to "B.5 Component Status" (page 977)
for details.
• Error Code
The component error code is displayed.
• Notes
Remarks are displayed.
- When "Parts" is "Memory", the memory capacity is displayed.
- When "Parts" is "SCU", the voltage information is displayed (for the ETERNUS DX80 S2/DX90 S2).
■ View
