Chapter 7 Thin Provisioning Pool Management
7.2 Functions in the Action Area for Thin Provisioning
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
226
→ The screen returns to the previous screen. The created RAID group is displayed in the RAID group list.
5 When creating multiple RAID groups that configure a TPP, repeat Step 3 and Step 4.
Drives can be selected from the list of drives that is displayed for Tabular or from the drive images that
are displayed for Graphic. Click the Tabular tab to display a list of the drives or click the Graphic tab to
display drive images.
An error screen appears in the following conditions:
• When the number of selected drives and the number of member drives of the specified RAID type
do not match
• When the number of selected drives and the number of member drives of the existing RAID group
do not match
• To check the number of member drives of the RAID group, click the [RAID Type] link for the existing
RAID group. The drives with the checkbox selected in the displayed screen are the member of the
RAID group.
• Click the [RAID Type] link to change the controlling CM and configuration drives of the RAID group.
• Click the [Delete] button to delete a RAID group.
