Chapter 11 System Management
11.2 Functions in the Action Area for System
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
845
The procedure to delete a key group is as follows:
Procedure
1 Click [Delete Key Group] in [Action].
→ A confirmation screen appears.
2 Click the [OK] button.
→ Deleting of the key group starts.
3 Click the [Done] button to return to the [Key Group] screen.
End of procedure
11.2.6.8 Modify Key Group
This function changes the key group settings.
The key group combines all of the RAID groups that use the same key.
The procedure to change the key group settings is as follows:
Procedure
1 Click [Modify Key Group] in [Action].
2 Specify the parameters, and click the [Modify] button.
• Name
Input a key group name.
The key group name corresponds to "Serial Number", which is managed in the key server.
The following input conditions apply:
- Up to 32 alphanumeric characters and symbols (underscore "_")
- The first letter must be an alphabetic character
Do not change the key group name after the key status changes to "Normal". The key status can be
checked on the [Key Group] screen. Refer to "11.1.5.1 Key Group" (page 723)
for details.
