Chapter 9 Connectivity Management
9.2 Functions in the Action Area for Connectivity
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
443
3 Register a host in a host group in the following procedures.
■ When registering a host by selecting from the host list
(1) Click the [Now Connected] tab.
(2) Select a host that is to be registered from the FC host list, and click the [Add] button.
- Checkbox to select a host
Select the FC host checkbox to be registered in a host group.
→ A confirmation screen appears.
Filter setting
Filter Description
WWN
Input the WWN that is to be displayed.
FC hosts matching or partially matching the input WWN are displayed.
When not using the WWN for filtering, leave this item blank.
Host Group
Input the host group name that is to be displayed.
FC hosts which belong to any host groups that match or partially match the entered
name are displayed.
When not using the host group name for filtering, leave this item blank.
Host Response
Select the host response that is to be displayed.
Any FC hosts that are allocated to the selected host response are displayed.
