Chapter 10 Component Management
10.1 Component Status
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
629
■ Rear View
The image that is displayed in this screen varies depending on the storage system model.
● For ETERNUS DX80 S2/DX90 S2
The following items are displayed in the Main area:
- Device image
The rear view of the CE that is installed in the ETERNUS DX Disk storage system is displayed.
The CM status and the Power Supply Unit (PSU) status are displayed with icons.
By clicking the CM number, the [Controller Module] screen is displayed. Refer to "10.1.5 Controller
Module Detail" (page 652) for display items.
By clicking the PSU number, the [Controller Enclosure Power Supply Unit] screen is displayed. Refer to
"10.1.11 PSU/CPSU (CE) Detail" (page 664)
for display items.
- Parts
The CM number or the PSU number is displayed.
By clicking the CM number, the [Controller Module] screen is displayed. Refer to "10.1.5 Controller
Module Detail" (page 652) for display items.
By clicking the PSU number, the [Controller Enclosure Power Supply Unit] screen is displayed. Refer to
"10.1.11 PSU/CPSU (CE) Detail" (page 664)
for display items.
- Status
The CM status or the PSU status is displayed. Refer to "B.5 Component Status" (page 977)
for details.
