Chapter 10 Component Management
10.1 Component Status
ETERNUS Web GUI User’s Guide
Copyright 2013 FUJITSU LIMITED P2X0-1090-10ENZ0
656
- For ETERNUS DX410 S2/DX440 S2
• 8G-FC 2port
• 8G-FC 4port
• 16G-FC 2port
• 16G-FC 4port
• 10G-iSCSI 2port
• 1G-iSCSI 2port
• 10G-FCoE 2port
• 1G-iSCSI-RA 2port
- For ETERNUS DX8100 S2/DX8700 S2
• 8G-FC 2port
• 8G-FC 4port
• 16G-FC 2port
• 16G-FC 4port
• 10G-iSCSI 2port
• 1G-iSCSI 2port
• 10G-FCoE 2port
• 1G-iSCSI-RA 2port
• Status
The CA status is displayed. Refer to "B.5 Component Status" (page 977)
for details.
• Status Code
The CA status code is displayed.
• Part Number
The CA part number is displayed.
• Serial Number
The serial number of the CA is displayed.
• Hardware Revision
The hardware version of the CA is displayed.
• Chip#n Status
The status of Chip#0 or Chip#1 is displayed. Refer to "B.5 Component Status" (page 977)
for details.
• Chip#n Status Code
The status code of Chip#0 or Chip#1 is displayed.
• Chip#n Error Code
The error code of Chip#0 or Chip#1 is displayed.
• Chip#n Active EC
The Edition Control (EC) number of the currently running Chip#0 or Chip#1 is displayed.
• Chip#n Next EC
The EC number of the Chip#0 or the Chip#1 that is to be run at the next power-on is displayed.
The 1-port type CA provided by ETERNUS DX80 S2 is also displayed as a 2-port type. To determine whether
the CA is 1-port type or 2-port-type, refer to the port number displayed in the [Internal Parts] tab. Note
that 1-port type CAs are not available in some regions.
