Configuring System Information
48
ProSafe M5300 Switch
Type of Binding Specifies the type of binding for the pool.
• Unallocated
• Dynamic
• Manual
Network Address Specifies the subnet address for a DHCP address of a dynamic pool.
Network Mask Specifies the subnet number for a DHCP address of a dynamic pool. Either
Network Mask or Prefix Length can be configured to specify the subnet mask
but not both.
Network Prefix Length Specifies the subnet number for a DHCP address of a dynamic pool. Either
Network Mask or Prefix Length can be configured to specify the subnet mask
but not both. Valid Range is (0 to 32)
Client Name Specifies the Client Name for DHCP manual Pool.
Hardware Address Specifies the MAC address of the hardware platform of the DHCP client.
Hardware Address Type Specifies the protocol of the hardware platform of the DHCP client. Valid types
are ethernet and ieee802. Default value is ethernet.
Client ID Specifies the Client Identifier for DHCP manual Pool.
Host Number Specifies the IP address for a manual binding to a DHCP client. Host can be
set only if at least one among of Client Identifier or Hardware Address is
specified. Deleting Host would delete Client Name, Client ID, Hardware
Address for the Manual Pool and set the Pool Type to Unallocated.
Host Mask Specifies the subnet mask for a manual binding to a DHCP client. Either Host
Mask or Prefix Length can be configured to specify the subnet mask but not
both.
Host Prefix Length Specifies the subnet mask for a manual binding to a DHCP client. Either Host
Mask or Prefix Length can be configured to specify the subnet mask but not
both. Valid Range is (0 to 32)
Lease Time Can be selected as “Infinite” to specify lease time as Infinite or “Specified
Duration” to enter a specific lease period. In case of dynamic binding infinite
implies a lease period of 60 days and In case of manual binding infinite implies
indefinite lease period. Default Value is “Specified Duration”.
Days Specifies the Number of Days of Lease Period. This field appears only if the
user has specified “Specified Duration” as the Lease time. Default Value is 1.
Valid Range is (0 to 59)
Hours Specifies the Number of Hours of Lease Period. This field appears only if the
user has specified “Specified Duration” as the Lease time. Valid Range is (0 to
22)
Minutes Specifies the Number of Minutes of Lease Period. This field appears only if the
user has specified “Specified Duration” as the Lease time. Valid Range is (0 to
86399)
Default Router Addresses Specifies the list of Default Router Addresses for the pool. The user may
specify up to 8 Default Router Addresses in order of preference.
Field Description
