Register
Abbreviation
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Module
ICRA ICRA7 ICRA6 ICRA5 ICRA4 ICRA3 ICRA2 ICRA1 ICRA0
ICRB ICRB7 ICRB6 ICRB5 ICRB4 ICRB3 ICRB2 ICRB1 ICRB0
ICRC ICRC7 ICRC6 ICRC5 ICRC4 ICRC3 ICRC2 ICRC1 ICRC0
ISR IRQ7F IRQ6F IRQ5F IRQ4F IRQ3F IRQ2F IRQ1F IRQ0F
ISCRH IRQ7SCB IRQ7SCA IRQ6SCB IRQ6SCA IRQ5SCB IRQ5SCA IRQ4SCB IRQ4SCA
ISCRL IRQ3SCB IRQ3SCA IRQ2SCB IRQ2SCA IRQ1SCB IRQ1SCA IRQ0SCB IRQ0SCA
INT
ABRKCR CMF — — — — — — BIE
BARA A23 A22 A21 A20 A19 A18 A17 A16
BARB A15 A14 A13 A12 A11 A10 A9 A8
BARC A7 A6 A5 A4 A3 A2 A1 —
FLMCR1 FWE SWE — — EV PV E P
FLMCR2 FLER — — — — — ESU PSU
FLASH
PCSR — — — — PWCKC PWCKB PWCKA — PWM
EBR1 — — — — — — — — FLASH
SYSCR2 — — — — — — — — SYSTEM
EBR2 EB7 EB6 EB5 EB4 EB3 EB2 EB1 EB0 FLASH
SBYCR SSBY STS2 STS1 STS0 SCK2 SCK1 SCK0
LPWRCR DTON LSON NESEL EXCLE — — — —
MSTPCRH MSTP15 MSTP14 MSTP13 MSTP12 MSTP11 MSTP10 MSTP9 MSTP8
MSTPCRL MSTP7 MSTP6 MSTP5 MSTP4 MSTP3 MSTP2 MSTP1 MSTP0
SYSTEM
SMR_1 C/A CHR PE O/E STOP MP CKS1 CKS0 SCI_1
ICCR_1 ICE IEIC MST TRS ACKE BBSY IRIC SCP IIC_1
BRR_1 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 SCI_1
ICSR_1 ESTP STOP IRTR AASX AL AAS ADZ ACKB IIC_1
SCR_1 TIE RIE TE RE MPIE TEIE CKE1 CKE0
TDR_1 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
SSR_1 TDRE RDRF ORER FER PER TEND MPB MPBT
RDR_1 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
SCMR_1 — — — — SDIR SINV — SMIF
SCI_1
ICDR_1 ICDR7 ICDR6 ICDR5 ICDR4 ICDR3 ICDR2 ICDR1 ICDR0
SARX_1 SVAX6 SVAX5 SVAX4 SVAX3 SVAX2 SVAX1 SVAX0 FSX
ICMR_1 MLS WAIT CKS2 CKS1 CKS0 BC2 BC1 BC0
SAR_1 SVA6 SVA5 SVA4 SVA3 SVA2 SVA1 SVA0 FS
