Register
Abbreviation
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Module
PAODR PA7ODR PA6ODR PA5ODR PA4ODR PA3ODR PA2ODR PA1ODR PA0ODR
PAPIN PA7PIN PA6PIN PA5PIN PA4PIN PA3PIN PA2PIN PA1PIN PA0PIN
PORT
PADDR PA7DDR PA6DDR PA5DDR PA4DDR PA3DDR PA2DDR PA1DDR PA0DDR
P1PCR P17PCR P16PCR P15PCR P14PCR P13PCR P12PCR P11PCR P10PCR
P2PCR P27PCR P26PCR P25PCR P24PCR P23PCR P22PCR P21PCR P20PCR
P3PCR P37PCR P36PCR P35PCR P34PCR P33PCR P32PCR P31PCR P30PCR
P1DDR P17DDR P16DDR P15DDR P14DDR P13DDR P12DDR P11DDR P10DDR
P2DDR P27DDR P26DDR P25DDR P24DDR P23DDR P22DDR P21DDR P20DDR
P1DR P17DR P16DR P15DR P14DR P13DR P12DR P11DR P10DR
P2DR P27DR P26DR P25DR P24DR P23DR P22DR P21DR P20DR
P3DDR P37DDR P36DDR P35DDR P34DDR P33DDR P32DDR P31DDR P30DDR
P4DDR P47DDR P46DDR P45DDR P44DDR P43DDR P42DDR P41DDR P40DDR
P3DR P37DR P36DR P35DR P34DR P33DR P32DR P31DR P30DR
P4DR P47DR P46DR P45DR P44DR P43DR P42DR P41DR P40DR
P5DDR — — — — — P52DDR P51DDR P50DDR
P6DDR P67DDR P66DDR P65DDR P64DDR P63DDR P62DDR P61DDR P60DDR
P5DR — — — — — P52DR P51DR P50DR
P6DR P67DR P66DR P65DR P64DR P63DR P62DR P61DR P60DR
PBODR PB7ODR PB6ODR PB5ODR PB4ODR PB3ODR PB2ODR PB1ODR PB0ODR
PBPIN PB7PIN PB6PIN PB5PIN PB4PIN PB3PIN PB2PIN PB1PIN PB0PIN
P8DDR P86DDR P85DDR P84DDR P83DDR P82DDR P81DDR P80DDR
P7PIN P77PIN P76PIN P75PIN P74PIN P73PIN P72PIN P71PIN P70PIN
PBDDR PB7DDR PB6DDR PB5DDR PB4DDR PB3DDR PB2DDR PB1DDR PB0DDR
P8DR — P86DR P85DR P84DR P83DR P82DR P81DR P80DR
P9DDR P97DDR P96DDR P95DDR P94DDR P93DDR P92DDR P91DDR P90DDR
P9DR P97DR P96DR P95DR P94DR P93DR P92DR P91DR P90DR
IER IRQ7E IRQ6E IRQ5E IRQ4E IRQ3E IRQ2E IRQ1E IRQ0E INT
STCR IICS IICX1 IICX0 IICE FLSHE ICKS1 ICKS0
SYSCR INTM1 INTM0 XRST NMIEG HIE RAME
MDCR EXPE — — — — — MDS1 MDS0
SYSTEM
BCR — ICIS0 BRSTRM BRSTS1 BRSTS0 — IOS1 IOS0
WSCR ABW AST WMS1 WMS0 WC1 WC0
BSC
