to a PCI bus. Reads result in data being returned by the xXB through the SAC to the system
bus.
• Otherwise, the access is forwarded to the xXB to be placed on the PCI bus (or AGP bus) as a
Configuration Read or Configuration Write cycle. Reads will result in data being returned
through the xXB and SAC back to the system bus, just as in normal Outbound Read
operations.
2.2 Access Restrictions
The 460GX chipset supports PCI configuration space access using the mechanism denoted as
Configuration Mechanism #1 in the PCI specification.
The 460GX chipset internal registers (both I/O Mapped and Configuration registers) are accessible
by the Host CPU. The registers can be accessed as Byte, Word (16-bit), or Dword (32-bit)
quantities, with the exception of CONFIG_ADDRESS which can only be accessed as a Dword. All
multi-byte numeric fields use “little-endian” ordering (i.e. lower addresses contain the least
significant parts of the field).
2.2.1 Partitioning
Each SAC, SDC, MAC, PXB, WXB, GXB, each AGP bus below an GXB, and each PCI bus below
an PXB or WXB, has an independent configuration space. None of the registers are shared between
the spaces; that is, the SAC, and each PCI bus in the PXB, have separate control and status
registers.
Configuration registers are accessed using an “address” comprised of the PCI Bus Number, the
Device Number within the bus, and the Register Number within the Device.
Accesses to devices on Bus #0 and Bus #(CBN) are serviced by the 460GX chipset depending on
their device number. Device 10h on Bus #0 is mapped to the SAC; it contains the programmable
Chipset Bus Number. All other chipset devices reside on bus CBN.
The DEVNPRES register is used to determine which chipset devices are present; see Table 2-1 for
mapping information.
Configuration registers located in the SDC are accessed over the private data bus. The SAC
translates CF8/CFC accesses to SDC registers into configuration commands over the PDB.
Configuration registers located on the memory boards are accessed over the I2C port. The SAC
Table 2-1. Device Mapping on Bus CBN
No. Device No. Device
00h SAC 10h Expander 0, Bus a
a
a. This is the compatibility bus (where the boot vector is always directed).
01h SAC 11h Expander 0, Bus b
02h reserved 12h Expander 1, Bus a
03h reserved 13h Expander 1, Bus b
04h SDC 14h Expander 2, Bus a
05h Memory Card A 15h Expander 2, Bus b
06h Memory Card B 16h Expander 3, Bus a
07h reserved 17h Expander 3, Bus b
08h-0Fh reserved 18h-1Fh reserved
