12.2.11 SIDETIM–Slave IDE Timing Register (Function 1)
Address Offset: 44h
Default Value: 00h
Attribute: Read/Write only
This register controls the IFB’s IDE interface and selects the timing characteristics for the slave
drives on each IDE channel. This allows for programming of independent operating modes for
each IDE agent. This register has no affect unless the SITRE bit is enabled in the IDETIM Register.
9:8 Recovery Time (RTC). This field selects the minimum number of PCI clocks between the last
IORDY# sample point and the DIOx# strobe of the next cycle.
Bits[9:8] Number of Clocks
00 4
01 3
10 2
11 1
7 DMA Timing Enable Only (DTE1). When DTE1=1, fast timing mode is enabled for DMA data
transfers for drive 1. PIO transfers to the IDE data port will run in compatible timing. When DTE1 =
0, both DMA and PIO data transfers for drive 1 will use the fast timing mode.
6 Prefetch and Posting Enable (PPE1). When PPE1=1, prefetch and posting to the IDE data port
is enabled for drive 1. When PPE1 = 0, prefetch and posting is disabled for drive 1.
5 IORDY Sample Point Enable Drive Select 1 (IE1). When IE1=0, IORDY sampling is disabled for
Drive 1. When the internal IORDY signal is forced asserted, IORDY is sampled asserted at the first
sample point as specified by the ISP field in this register.
When IE1=1 and the currently selected drive (via a copy of bit 4 of 1x6h) is Drive 1, all accesses to
the enabled I/O address range sample IORDY. The IORDY sample point is specified by the ISP
field in this register.
4 Fast Timing Bank Drive Select 1 (TIME1). When cleared, accesses to the data port will use
compatible timings for this drive. When set and bit 14 cleared, accesses to the data port will use
bits 13:12 for the IORDY sample point, and bits 9:8 for the recovery time. When set and bit 14 set,
accesses to the data port will use the IORDY sample point and recover time specified in the slave
IDE timing register.
3 DMA Timing Enable Only (DTE0). When DTE0=1, fast timing mode is enabled for DMA data
transfers for drive 0. PIO transfers to the IDE data port will run in compatible timing. When DTE1 =
0, both DMA and PIO data transfers for drive 0 will use the fast timing mode.
2 Prefetch and Posting Enable (PPE0). When PPE0 = 1, prefetch and posting to the IDE data port
is enabled for drive 0. When PPE0 = 0, prefetch and posting is disabled for drive 0.
1 IORDY Sample Point Enable Drive Select 0 (IE0). When IE0=0, IORDY sampling is disabled for
Drive 0. When the internal IORDY signal is forced asserted, IORDY is sampled asserted at the first
sample point as specified by the ISP field in this register.
When IE0=1 and the currently selected drive (via a copy of bit 4 of 1x6h) is Drive 0, all accesses to
the enabled I/O address range sample IORDY. The IORDY sample point is specified by the ISP
field in this register.
0 Fast Timing Bank Drive Select 0 (TIME0). When TIME0=0, accesses to the data port of the
enabled I/O address range uses the 16 bit compatible timing.
When TIME0=1 and the currently selected drive (via a copy of bit 4 of 1x6h) is Drive 0, accesses to
the data port of the enabled I/O address range use fast timings. PIO accesses to the data port use
fast timing only if bit 3 of this register (DTE0) is 0. Accesses to all non-data ports of the enabled I/
O address range always use the 8 bit compatible timings.
Bit Description
